Compact and manoeuvrable wall

Soundproof manoeuvrable walls made up of independent, individually operated elements.

Soundproof manoeuvrable walls made up of independent, individually operated elements.
Sliding along the ceiling rails with single and double-bar systems, without floor guides.
Aluminium slide rails, alloy EN – AW 6005 T6, anodised 20 micron thick.

Sound insulation index from RW=35 db to RW=58 db.
Surface finishes in CPL laminate in white, grey and ivory.

Wall thickness from cm 7.0 to cm 10.6
The function of the manoeuvrable wall is to form a partition that can be removed easily and quickly if necessary.

Since the panels of the maneuverable wall are literally hung on a top rail, the ceiling must be load-bearing. If this condition does not exist, the wall will be supplied complete with an adequate structure, suitably scaled and evaluated at the time of the survey.
